Product Details
Place of Origin: China
Brand Name: OEM/ ODM/ Lansan
Certification: CE/ RoHS/ ETL/ ISO
Model Number: BNC Connector
Payment & Shipping Terms
Minimum Order Quantity: 1000 pcs
Price: Negotiation
Packaging Details: 100pcs / bag
Delivery Time: 5-7 Work Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, Paypal
Supply Ability: 10000 Meters/ Day
Type: |
BNC Type Connector |
Applicaiton: |
RF |
Plating: |
Nickel |
Fastening Type: |
Snap-On |
Medium Pressure: |
1500V |
Applicable Standard: |
IEC 60169-24 |
Type: |
BNC Type Connector |
Applicaiton: |
RF |
Plating: |
Nickel |
Fastening Type: |
Snap-On |
Medium Pressure: |
1500V |
Applicable Standard: |
IEC 60169-24 |
Waterproof Compression BNC Connector for RG58 RG59 RG6 Coaxial Cable
Parameter
| Characteristic Impedance | 75ohm | |
| Frequency Range | DC-4GHz | |
| VSWR | ≤1.30@DC-1000MHz | |
| Insertion Losss | ≤0.2dB | |
| Working Vlotage | 500V RMS,50Hz,at sea level | |
| Dielectric Withstanding Voltage | ≥1500V RMS,50Hz,at sea level | |
| Dielectric Resistance | ≥5000MΩ | |
| Contact Resistance | Center Contact ≤1.5mΩ | Outer Contact ≤1.0 mΩ |
| Durability | Mating cycles ≥500 | |
| Parts Name | Material | Plating |
| Body | Brass | Ni |
| Insulator | PTFE | - |
| Inner Conductor | Phosphor Bronze | Au |
| Coupling Nut | Brass | Ni |
| Gasket | Silicone Rubber | - |
| Ferrule | Annealed Copper | Ni |
| Operating Temperature | _45 °C~-85 °C | |
| Weatherproof Rate | IP67 | |
| RoHs (2002/95/EC) | Compliant by exemption | |
Specificaiton
