96 Braiding Coaxial TV Cable 0.81mm Conductor 75OHM RG59

  • 96 Braiding Coaxial TV Cable 0.81mm Conductor 75OHM RG59
  • 96 Braiding Coaxial TV Cable 0.81mm Conductor 75OHM RG59
Place of Origin China
Brand Name OEM/ ODM/ Lansan
Certification CE/ RoHS/ ETL/ ISO
Model Number RG59
Minimum Order Quantity 15000 Meters
Price Negotiation
Packaging Details 100 Meters/ Box
Delivery Time 12-14 Work Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, Paypal
Supply Ability 100000 Meters/ Day
Product Details
Conductor Material Bare Copper Conductor Size 0.81mm
Braiding Al-M Insulation Foam PE
Jacket PVC Name Video Coaxial Cable
High Light

96 Braiding Coaxial TV Cable

,

0.81mm Conductor Coaxial TV Cable

,

75OHM Video Coaxial Cable
Leave a Message
Product Description

75OHM RG59 96 Braiding Bare Copper CATV Video Coaxial Cable



Characteristics



  • High velocity of propagation, low attenuation, low return loss;
  • Perfect connecting cable for digital video and audio signals for the highest quality image;
  • Perfect cable for satellite TV & high speed internet;
  • Durable & flexible PVC jacket is ideal for running cable through dry wall and over drop ceilings girders;
  • Allows for bending cable without damaging the quad shielded insulated wiring

​

Specification



Name Material Parameter
Inner conductor Bare copper 0.81 mm (diameter)
Dielectric Physical foam PE 3.66 mm (diameter)
First shield Bonded aluminum foil 3.84 mm (diameter)
Second shield Aluminum braid 67% or 95% coverage
Jacket PVC or PE 6.10 mm (diameter)
Messenger N/A N/A





Attenuation at 20ºC



Frequency (MHz) 5 55 300 500 750 1000
Maximum(dB/100m) 2.82 6.73 14.60 18.70 22.87 26.64
