PVC Jacket AL Foil CCS PVC Coaxial TV Aerial Cable
| Place of Origin | China |
|---|---|
| Brand Name | OEM/ ODM/ Lansan |
| Certification | CE/ RoHS/ ETL/ ISO |
| Model Number | RG6 |
| Minimum Order Quantity | 15000 Meters |
| Price | Negotiation |
| Packaging Details | 100 Meters/ Box |
| Delivery Time | 12-14 Work Days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, Paypal |
| Supply Ability | 100000 Meters/ Day |
Product Details
| Wire Core Material | CCS Wire | Material Shape | Round Wire |
|---|---|---|---|
| Type | RG6 Coaxial Cable | Jacket | PVC,PE |
| Brand | OEM | Orgin | China |
| High Light | PVC Coaxial TV Aerial Cable,CCS Coaxial TV Aerial Cable,AL Foil Coaxial Cctv Cable |
||
Product Description
High Speed RG59 CCS PVC Coaxial TV Cable For CCTV System CE Certification
Parameter
- Center conductor:BC,TC,CCA,CCS
- Al-foil:Non-bonded Al-foil, bonded Al-foil,double bonded Al-foil,and double non-bonded Al-foil
- Braiding wire:Al,BC,,TC,CCA,CCS
- Braiding wire diameter:0.10,0.11,0.12,0.13,0.14,0.15,0.16mm
- Braiding net:32,48,64,72,80,96,120,128,144 and more
- Braiding coverage:Between 30-97%
- PVC jacket of flame retardant,UL
RG6 Comparing
| ITEM | RG6SM | RG6S | RG6T |
| Center conductor | 1.02mm + 0.01mm | 1.02mm + 0.01mm | 1.02mm+ 0.01mm |
| Dielectric | 4.75+0.05mm FPE | 4.75+0.05mm FPE | 4.75+0.05mm FPE |
| Shield | Bonded AL Foil | Bonded AL Foil | Bonded AL Foil |
| Braid coverage | 60% | 60% | 60% |
| Shield | Al Foil | ||
| Braid coverage | 40% | ||
| Jacket | 6.91+0.05mm PVC |
6.91+0.05mm
PVC
|
7.06+0.05mm
PVC
|
| Messenger | 1.30mm |
