Product Details
Place of Origin: China
Brand Name: OEM/ ODM/ Lansn
Certification: UL/ CE/ ETL/ ROHS/ ANATEL
Model Number: CAT5E UTP
Payment & Shipping Terms
Minimum Order Quantity: 50 Rolls
Price: Negotiation
Packaging Details: 305 meters/ Wooden spool
Delivery Time: 12-15 Work Day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 5000 Box/Day
Conductor: |
24AWG Solid Bare Copper |
Cord: |
4Pairs |
Jacket: |
PVC + PE |
Color: |
All Kinds Of Color |
Bend Radius: |
4 X Cable Diameter |
Origin: |
Shenzhen, China |
Conductor: |
24AWG Solid Bare Copper |
Cord: |
4Pairs |
Jacket: |
PVC + PE |
Color: |
All Kinds Of Color |
Bend Radius: |
4 X Cable Diameter |
Origin: |
Shenzhen, China |
Computer 4Pairs UTP Cat5e 0.50mm Pure Copper PVC + PE Outdoor Lan Cable
Overview
High-Performance data cable ,application structured cabling, CCTV system , Alarm system , Telecom project etc.
Exceeds TIA/EIA-568B.2,ISO/IEC 11801 , ETL listed .
100Base-TX,100Base-T2 and 100Base-T4 standard.
Can be used for voice, integrated service data network (ISDN).
Long transmission distance, small transmission loss, wear resistance, resistance to pressure.
Electrical Performance
| 1.0`250.0MHz Impedance(ohms) | 100±15 |
| 1.0~250.0MHz Delay Skew(ns/100m) | ≤45 |
| 20ºC Conductor D.C, Resistance(ohms/km) | ≤65.8 |
| Unbalance of Pair(%) | ≤1.0 |
Specification
| Model | outdoor cat5e utp lan cable |
| Conductor Size | 24AWG |
| 0.45mm/0.48mm/0.49mm/0.5mm/0.51mm | |
| Conductor Material | CCA/CCU/BC |
| Nuber Of Conductor | 4P |
| unShiled | UTP |
| Flammability Grade: | CM,CMR,CMP |
| Indoor / Outdoor | Single jacket/Double jacket |
| Insulation Material | HDPE |
| Insulation Thickness | 0.91mm |
| Jacket Material | PVC, ROHS PVC, LSZH PVC |
| Outer Jacket Thickness | 5.2mm |
| DC Resistance(Max.) | 9.5 Ohm/100m |
| DC Resistance Imbalance | 2.50% |
| Working Capacitance(Max.) | 5.4nF/100m |
| Insulation Resistance | 10000 MOhm.km |
| Transmission Velocity | 65% |
| Operating Temperation | -40 °C - +75 °C |
| PVC Jacket Color | As client's request. |
| Marking On Jacket | On your request (Print your brand) |
| Construcation | 4Pairs +PVC +PE Jacket 8 conductors ,Insulation ,Ripcord ,double jackets |
