ABS/PC Male CAT5E UTP Shielded Network Cable Assembly

Product Details

Place of Origin: China

Brand Name: OEM / ODM / LANSAN

Certification: CE / ROHS / UL / ISO / ETL / Anatel

Model Number: RJ45 Cat5e UTP

Payment & Shipping Terms

Minimum Order Quantity: 5000 Pcs

Price: Negotiate

Packaging Details: 100 Pcs Per Bag

Delivery Time: 12 - 15 Working Day

Payment Terms: L/C, T/T, Western Union

Supply Ability: 100000 Pcs Per Day

Get Best Price
Highlight:

Toolless RJ45 Modular Plug

,

UTP Ethernet Rj45 Connector Plug

Type:
Ethernet Rj45 Connector
Sheild:
UTP
Gold-Plated:
FU/3U/15U/50U
Gender:
Male
Classification:
RJ45
Certification:
UL / CE
Test:
100% Fluke Test Passed
Material:
ABS/PC
Type:
Ethernet Rj45 Connector
Sheild:
UTP
Gold-Plated:
FU/3U/15U/50U
Gender:
Male
Classification:
RJ45
Certification:
UL / CE
Test:
100% Fluke Test Passed
Material:
ABS/PC
ABS/PC Male CAT5E UTP Shielded Network Cable Assembly

CAT5E UTP Shielded Network Cable Assembly Toolless RJ45 modular plug



We offer modular Plugs in standard configuration terminate modular cords for patching or work area application, modular plugs can be terminated to the exact cable length in order to maintain a nearer, more organized installment, the plugs terminated twist pair cable with 22-26 AWG solid all plugs contracts have 50 micron inched of good plating over nickel.



SPECIFICATION

RJ45 Cat5E UTP Male Connector/ Patch Plug Category 6 &8P8C Gold plating: 3"-50u" over nickel

1.8 pin x 8 conductor

2.Current Rating:1.5 amps

3.Voltage Rating:125vac

4.Insulation Resistance:500 MΩmin

5.Contact Resistance:30 MΩmax

6.Withstanding Voltage:AC 1000V RMS 50Hz or 60Hz 1 min



MECHANICAL

1.Insertion Force:2.2KG.F max

2.Retention Strength:7.7KG.F min between jack and plug

3.Durability:600 mating cycles min



MATERIAL

1. PC

2. Contact Wire:Diameter 0.45mm phosphor bronze gold plating over nickel 0.35mm thickness phosphor bronze alloy selective gold plating over nickel

3. Shield:0.20~0.25mm thickness brass with tin plated

4.Gold Plating:3u inch,6u inch,15u inch,30u inch,50u inch



ENVIRONMENTAL

Working Temperature:-40°C to 70°C



Competitive Advantage

  • For price, our offer can be much more competitive than other suppliers such as the trading company, as we have our own factory.
  • For quality, our superior raw material, skilled production team, advanced equipment and mature quality control system could assure you of that we could offer the cable with high and consistent quality.
  • For production capacity, we could produce 30 million meters cable monthly, which will assure you of prompt delivery of the goods.
  • Certificates: ISO, CE, CCC,ETL, RoHS ,ANATEL & UL approval.​
