ABS PC 22-26AWG Wire Unshielded RJ45 Cat6 Modular Plugs

Product Details

Place of Origin: China

Brand Name: OEM / ODM / LANSAN

Certification: CE / ROHS / UL / ISO / ETL / Anatel

Model Number: RJ45 Cat6 UTP

Payment & Shipping Terms

Minimum Order Quantity: 5000 Pcs

Price: Negotiate

Packaging Details: 100 Pcs Per Bag

Delivery Time: 12 - 15 Work Day

Supply Ability: 10000 Pcs Per Day

Get Best Price
Highlight:

26AWG Rj45 Modular Plug

,

Unshielded Ethernet rj45 connector

,

ABS PC Rj45 Modular Plug

Sheild:
UTP
Type:
Ethernet Rj45 Connector
Number Of Slots:
8 PIN
Supports:
22-26AWG Wire
Test:
100% Fluke Test Passed
Certification:
ROHS / UL
Material:
ABS / PC
Category:
Cat6
Sheild:
UTP
Type:
Ethernet Rj45 Connector
Number Of Slots:
8 PIN
Supports:
22-26AWG Wire
Test:
100% Fluke Test Passed
Certification:
ROHS / UL
Material:
ABS / PC
Category:
Cat6
ABS PC 22-26AWG Wire Unshielded RJ45 Cat6 Modular Plugs

UL / RoHS compliant Cat6 Unshield RJ45 Modular Plug Fluke Test Passed



We offer modular Plugs in standard configuration terminate modular cords for patching or work area application, modular plugs can be terminated to the exact cable length in order to maintain a nearer, more organized installment, the plugs terminated twist pair cable with 22-26 AWG solid all plugs contracts have 50 micron inched of good plating over nickel.



SPECIFICATION



RJ45 Cat6/6A UTP Male Connector/ Patch Plug Category 6 &8P8C Gold plating: 3"-50u" over nickel



1. 8 pin x 8 conductor

2. Current Rating:1.5 amps

3. Voltage Rating:125vac

4. Insulation Resistance:500 MΩmin

5. Contact Resistance:30 MΩmax

6. Withstanding Voltage:AC 1000V RMS 50Hz or 60Hz 1 min



MECHANICAL



1. Insertion Force:2.2KG.F max

2. Retention Strength:7.7KG.F min between jack and plug

3. Durability:600 mating cycles min



MATERIAL



1. PC

2. Contact Wire:Diameter 0.45mm phosphor bronze gold plating over nickel 0.35mm thickness phosphor bronze alloy selective gold plating over nickel

3. Shield:0.20~0.25mm thickness brass with tin plated

4.Gold Plating:3u inch,6u inch,15u inch,30u inch,50u inch



ENVIRONMENTAL



Working Temperature:-40°C to 70°C



Competitive Advantage

  • For price, our offer can be much more competitive than other suppliers such as the trading company, as we have our own factory.
  • For quality, our superior raw material, skilled production team, advanced equipment and mature quality control system could assure you of that we could offer the cable with high and consistent quality.
  • For production capacity, we could produce 30 million meters cable monthly, which will assure you of prompt delivery of the goods.
  • Certificates: ISO, CE, CCC,ETL, RoHS ,ANATEL & UL approval.​
